Improvements over the previous model:
- One piece contruction
- No need to open the hub for wheel assembling / spoke replacement
- More equalized spoke camber on each side
- Can handle a higher spoke tension
Spoke number: 24h only
Material: special 7075TX
Bearings: 2x 15-24 2RS ABEC5
Micro-Tuner: quickest bearing preload system
Finishing: "hart coat" sides, black anodized body
Construction: 15mm oversized hi-engineered axle
Compatibility: 100mm TA 12mm forks and 100mm QR , convertible
Bearing options: Enduro ABEC 5, ABI Enduro 440-stainless, HDC Ceramic, XD15 Ceramic.
Graphics: laser etched
Here you will find pre-calculated spoke lengths, spoke patterns and wheel building tips.
Specifically designed for Road disc use.
Straight pull spokes increase wheel stiffness under sprinting. They sensibly reduce lateral flex and increase disc braking torque transmission.
allows an easy and quick bearing preload adjustment,
precise hub bearing setting ensures low bearing friction and no-play at the rim.
Hub body fanges receive our new special treatments (military standard) to handle lacing and breaking stress.
Hi-tech rarely combines with maintenance easiness, not here!
As every Extralite products CyberHubs exceedes UNI/DIN Safety standards. Safety tests simulate a very strong 90kg (200lb) rider output.
100% made in Italy
